NIISM101 – NITROGEN INFLATOR – LIGHT VEHICLE
Description
DaTo provides the best of the concept Nitrogen Inflator, where in the Air filled in the tires of the vehicles are directly changed and filled in with Nitrogen.
The machine directly generated Nitrogen from the Air and also displays the rated pressure and the purity of Nitrogen content in the Wheels.
Most adequate and simple to operate machine;
FEATURES:
- Suitable for Motorcycles, Cars etc.
- Digital display with easy operation steps
- Auto Start Inflation
- Over Pressure Setting (OPS)
- Single Tire Application
- Nitrogen Purity Test Report
- Adjustable lower purge pressure limit
TECHNICAL DATA SUMMARY
| Application | Motorcycle, Car |
| Built-in Automatic tire Inflator | Yes |
| Power Requirement | 100-240Vac 50/60HZ |
| Power Consumption | 28VA |
| Operating Temperature Range | -20°C/-4°F to 70°C/158°F |
| Maximum Compressed Air Input | 123PSI/8.5bar/850kPa |
| Compressed Air Input Flow | 280L/min (10.0cfm) |
| Nitrogen Purity | 95-99+% |
| Nitrogen Output* | 62L/min (2.2cfm) |
| Maximum Nitrogen Pressure in Tank | 102PSI/7bar/700kPa |
| Maximum Inflator Set Pressure | 90PSI/6.2bar/620kPa |
| Minimum Inflator Set Pressure | 5PSI/0.3bar/35kPa |
| Over Pressure Setting (OPS) | 0-29PSI/0-2.0bar/0-200kPa |
| Nitrogen Purge and Fill Cycle (N2P) | 0-9 |
| Inflator Accuracy | ±1PSI/0.07bar/7kPa |
| Units of Measurement | PSI/bar/kPa |
| Pre-Filter/s | Yes |
| Internal Nitrogen Storage Tank | Yes |
| External Nitrogen Storage Tank | No |
| Inflator Display | Large backlight LCD |
| Nitrogen Outlet/s | 2 |
| 8M/26ft Hose with Closed Chuck | 2 |
| Nitrogen Purity Test Port | Yes |
| Adjustable Lower Purge Pressure Limit | Yes |
| Auto-Start Inflation | Yes |
| Automatic Zero Drift Adjustment | Yes |
| Vandal Resistant Mechanical Switches | Yes |
| Net Weight | 103kg/227.1lbs |
| Gross Weight | 125kg/275.5lbs |
| Dimensions (Height*Width*Depth) | 1315*720*620(mm) |
