DaTo PBBCF124 Heavy Duty Vehicle Paint Booth | Industrial Paint Booth for Trucks & Buses
Built for large‑scale performance, the DaTo PBBCF124 Heavy Duty Paint Booth offers unmatched versatility and industrial‑grade airflow for painting heavy vehicles, buses, and commercial fleets. Its clear‑floor, side‑suction design ensures even airflow and easy vehicle access, while the 15 m‑long, 5 m‑wide cabin accommodates everything from heavy trucks to smaller passenger vans.
DaTo PBBCF124 Heavy Duty Vehicle Paint Booth – Engineered for Trucks, Buses & Commercial Vehicles
The booth includes a remote‑controlled electric roller shutter that divides the chamber into two independent sections — enabling simultaneous painting of two vehicles or color variants. Each half is equipped with individual controls, dual painter entry doors, and a dedicated Italian diesel burner for flexible and efficient operation.
Powered by four 11.5 kW blower motors, the system delivers a powerful 72,000 m³/h air volume, maintaining a constant dust‑free environment and high air velocity for premium finishes.
Key Features & Capabilities
-
Heavy‑Duty Design – Specialized for trucks, buses, and other commercial vehicle painting.
-
High Airflow Capacity – Delivers 72,000 m³/h via four 11.5 kW blowers for powerful, balanced air circulation.
-
Dual‑Zone Configuration – Motorized roller shutter divides the booth into two working zones with independent controls.
-
Dual Italian Diesel Burners – Ensures quick baking, uniform drying, and consistent high‑gloss finishes.
-
Clear Floor System – Simplifies cleaning and allows unrestricted vehicle movement during operations.
-
Side Suction Airflow – Provides even air displacement, reducing overspray and supporting uniform coating.
-
Safer Working Conditions – Advanced exhaust removes paint particles and fume hazards to ensure operator health.
-
Durable Construction – Puff‑insulated panels enhance heat retention, reduce energy loss, and extend service life.
-
Energy Efficient & Reliable – Industrial performance with controlled power consumption.
-
Customizable Length & Options – Adaptable to specific workshop sizes or paint applications.
Technical Highlights
| Parameter | Specification |
|---|---|
| Design Type | Heavy‑Duty Vehicle Paint Booth |
| Airflow Volume | 72,000 m³/h |
| Chamber Dimensions | 15 m (L) × 5 m (W) |
| Blower Configuration | 4 × 11.5 kW Motors |
| Burners | 2 × Italian Diesel Burners |
| Division System | Remote‑Controlled Electric Roller Shutter |
| Operating Zones | 2 Independent Painting Sections |
| Airflow Design | Side Suction with Clear Floor |
| Entry/Exit | Dual Painter Entry Doors |
| Application | Heavy Trucks, Buses, Commercial Vehicles |
| Build Type | Puff‑Insulated, Heat‑Resistant Steel Panels |
| Safety Features | Exhaust Filtration & Pollution‑Free Environment |
| Energy Efficiency | Balanced Heating & Optimized Air Velocity |
Specifications
| PARAMETER | HEAVY DUTY PBBCF124 | PARAMETER | HEAVY DUTY PBBCF124 |
| Overall Dimension (m) | 15.2*6.6*5.0 | Working Temperature ( °C) | 60°C~80°C |
| Inner Dimension (m) | 15*5.0*4.4 | Oil Consumption (kg/set) | 18~30 |
| Drive Through Door Width (m) | 4.0 | Insulation material of Wall Panel | PE |
| Drive Through Door Height (m) | 4.0 | Power (KW) | 50 |
| Steel Plate Thickness (mm) | 0.476 | Main Blower | Two units 11.5 KW Professional Blowers & Two Unit 11.5 KW Professional Blower |
| Filtrated Area (m²) | 49 | Ventilation Times (times/hr) | 264 |
| Air Flow Volume (m³/h) | 72000 | Air Velocity within booth (m/s) | 0.3~0.5 |
| Eco Friendly System | Optional | Second Row Nether Lighting | Equipped with 8 sets |
Why Choose DaTo PBBCF124 Heavy Duty Paint Booth?
-
Designed for industrial‑scale body shops with enhanced airflow and chamber capacity.
-
Flexible dual‑section control enables painting two vehicles or colors simultaneously.
-
Reduces rework and refinish time, offering factory‑grade paint quality on heavy vehicles.
-
Minimizes environmental impact with efficient exhaust filtration and low power consumption.
-
Supported by DaTo’s expertise in automotive painting and after‑sales service excellence.
