SHOP PRESS ASHP1020, ASHP 1030
Product Overview:
The ASHP 1030 is a hydraulic 30 TON Shop Press. The ASHP1030 is used for removing and installing bearings, gears, U-joints, bushings, ball joints, pulleys, and more. This Hydraulic Shop Press exerts up to 30 TONS of pressure by simply pumping a lever.
Features:
- Engineered to be used for straightening, bending, holding, forming, pressing or other unique high pressure applications.
- Normal applications include installing bearings, bushings, gears, U joints, pulleys, ball joints, repairing engines & more.
- Heavy duty steel construction for maximum durability.
- Adjustable press bed height-8 Positions (4″ Between Each Position)
- Hydraulic Dual return springs retract arm.
- Steel cross brace prevents the frame from spreading under load.
- Automatic hydraulic bypass and overload systems protect arm and use
Product Specifications:
Type: Hydraulic
Max Pressure: 30 TON
Stroke: 6 1/2″
Overall Height: 66 1/2″
Working Width: 23 1/2″
Floor Print Width: 29 1/2″
Floor Print Length: 28″
