Details
Specification
|
Atomization Technology |
HVLP |
MP |
|
|
Model |
TH301AG |
||
|
Nozzle Range |
1.0-2.5mm |
||
|
Pattern (1.3MM) |
260-300mm |
||
|
10.2-11.8in |
|||
|
Recommended Air Inlet Pressure |
2bar |
2-2.2bar |
|
|
29psi |
29-32psi |
||
|
Air Consumption |
430l/min |
285l/min |
|
|
15.2cfm |
10cfm |
||
|
Air Inlet |
G/NPT 1/4" |
||
|
Cup |
600ml plastic |
||
|
Weight(gun only) |
430g |
||
|
Material |
Body |
Die-casted Aluminum |
|
|
Air Cap |
Special Selected Brass |
||
|
Nozzle/Fluid Tip |
High Grade Stainless Steel |
||
|
Needle |
High Grade Stainless Steel |
||
