CSC1E250 – 500L Compressor
Description
DaTo Compressor Most Renowned Industrial Air Compressor & Screw Air Compressor Supplier in Dubai, UAE
The DaTo Compressor Series are refined to supply dedicated and rated pressure to enable consistent pressure rating for the equipment’s connected to the Pneumatic line. To assure the safety of operation, safety check valve and pressure switch with Automatic On and Off function has also been provided.
To enhance the durability of the engine, the Compressor head has been provided with Air Filters and heavy duty copper wound motors too
Specification |
|
| Model | CSC1E250 |
| Power | 7.5Kw |
| Voltage | 380V/50Hz |
| Current | 15.6A |
| Cylinder | 105(MM)X2,55(MM)X1 |
| Air delivery | 1050L/min, 37.5CFM |
| Pressure | 180PSI, 12.5bar |
| Speed | 660RPM |
| Tank | 500L |
| Max | 12.5 bar |
| Net Weight | 300KG |
| Gross Weight | 310KG |
| Mass | 1600x600x1030mm |
