STAINLESS STEEL OVEN – SSOD980
Box heat treatment furnace is a flexible single chamber furnace designed for meet many processing requirements. The Box Furnaces are used for normalizing, annealing, quenching, tempering, hardening and other high temperature thermal processes for carbon steel, alloy steel, high-speed steel and other metal parts with different heating method in electric, direct fired or indirect gas fired.
Technical Parameters
| Item | Unit | Technical Parameters |
| Voltage | V | 380 |
| Frequency | Hz | 50 |
| Power | Kw | ≤9KW |
| Temperature Control Range | ◦C | 10-250 |
| Temperature Fluctuations | ◦C | ±1 |
| Timing Range | Min | 1-999 |
| Load Grid Plate | Block | 4 |
| Load Cell Height | Mm | 320 |
| Volume | l | 980 |
| Tank Size Distribution | Mm | 100+320+320+320+470 |
| Independent Over Temperature Protection Status | – | Sound and light alarm constant temperature state |
| Inside Size(H*W*D) | mm | 1480*800*800 |
| Out Side(H*W*D) | mm | 1780*1070*1060 |
| Net Weight | Kg | 260 |
| Gross Weight | Kg | 300 |
