WBL2412 – WHEEL BALANCER – LCD DISPLAY
DaTo Wheel Balancer – WBL2412 adopts the new LSI (Large Scale Integrated circuit) to constitute the hardware system that acquires processes and calculates information at a high speed. Equipped with 15” LCD screen and self-designed software, this equipment displays the data in a more intelligent way.
Specifications
| Max wheel weight | 65Kg |
| Motor power | 200W |
| Power supply | 220V/50Hz |
| Balancing precision | ±1g |
| Rotating speed | 200r/min |
| Position accuracy | 1.5° |
| Cycle time | 8s |
| Rim diameter | 10″~24″(256mm～610mm) |
| Rim width | 1.5″~20″(40mm～510mm) |
| Noise | ＜70dB |
| Net weight | 105kg |
| Dimensions | 960mm×760mm×1160mm |
Features
- Adopt high-definition LCD screen, 3D animation interface. Intelligent LCD screen with dynamic message displaying makes all balancing mode operation visualized.
- Various balancing modes can carry out counterweights to stick, clamp, or hidden stick etc.
- Input data of rim automatically by measure scale.
- Intelligent self-calibrating and measure scale self-labeling function.
- Self-fault diagnosis and protection function.
- Applicable for various rims of steel structure and duralumin structure.
